Electromagnetic Feeder drive with one coil in the center
Electromagnetic feeder drives,bowl feeder drive,parts feeder drive,piezoelectric drive,pneumatical drive,explosion-proof drive Based on industry-standard, the electromagnetic drive can meet changing automation needs,including greater demands on equipment design and performance expectations. The electromagnetic drive employs the center-mount electromagnet arrangement, combined with a redesigned cross arm that delivers a simple, but effective and efficient means to power the unit consistently over the range of operation. Three spring banks join the base with the cross arm to provide consistency, stability, and simplified tuning. The round base construction provides an appealing and functional design. When enclosed with stainless or mild steel covers, the electromagnetic drive is ideal for industries demanding an aesthetic and clean appearance.
| Model | A | B | C | Parts Max. Loading(kg) | Top Bowl Max. Mass(kg) |
| BF-00 | 149 | 165 | 176 | 2 | 2 |
| BF-01 | 180 | 189 | 210 | 4 | 3 |
| BF-02 | 230 | 210 | 257 | 5 | 5 |
| BF-03 | 270 | 245 | 307 | 6 | 8 |
| BF-04 | 320 | 285 | 350 | 8 | 12 |
| BF-05 | 370 | 277 | 400 | 10 | 15 |
| BF-06 | 425 | 317 | 469 | 30 | 35 |
| BF-07 | 505 | 367 | 550 | 40 | 40 |
Electromagnetic Feeder drive with one/two/four coils around
| Model | A(mm) | B(mm) | C(mm) | Parts Max. Loading(kg) | Top Bowl Max. Mass(kg) |
| BFA-01 | 145 | 186 | 160 | 3 | 5 |
| BFA-01 | 239 | 242 | 267 | 7 | 8 |
| BFA-02 | 308 | 241 | 343 | 10 | 15 |
| BFA-03 | 395 | 296 | 442 | 15 | 25 |
| BFA-04 | 420 | 317 | 469 | 30 | 35 |
| BFA-05 | 508 | 367 | 548 | 40 | 40 |
